Raspberry Pi 5 NVMe Compatibility List: Vendors Disagree
Someone on the Pimoroni forum did everything right. They checked the vendor's incompatibility list before buying an NVMe drive for a Raspberry Pi 5, and their WD Black SN770 was not on it. They bought it, set PCIE_PROBE=1 and dtparam=pciex1_gen=3, reseated the ribbon cable, and posted a thread titled Not Detected! Nobody had answered it.
That failure is not bad luck. I pulled the two most-cited Raspberry Pi 5 NVMe compatibility lists and lined them up drive by drive, and they contradict each other on most of what they share.
Two vendor lists, ten shared drives, two agreements
The sources are Geekworm's NVMe SSD Incompatibility List (14 banned models, page last modified 2026-06-03) and SunFounder's Pironman 5 compatibility page (44 rows marked Verified, 27 Generally Stable, 11 Compatible — May Vary, 7 Not Recommended). SunFounder rates 10 of Geekworm's 14. Here is every one of those ten.
| Drive | Geekworm | SunFounder | Result |
|---|---|---|---|
| WD Blue SN550 | Avoid (tagged Solved!) | Verified, 256GB | Contradiction |
| WD Blue SN580 | Avoid | Verified, 512GB | Contradiction |
| fanxiang S500 Pro | Avoid (MAP1202) | Verified, 256GB | Contradiction |
| Kingston NV3 | Avoid | Verified as SNV3S, 1TB | Contradiction |
| WD Blue SN5000 | Avoid | May Vary | Downgraded |
| WD Black SN770 | Avoid | May Vary | Downgraded |
| WD Black SN850 | Avoid | May Vary | Downgraded |
| Corsair MP600 | Avoid | May Vary | Downgraded |
| WD SN740 | Avoid | Not Recommended | Agreement |
| Inland TN446 | Avoid | Not Recommended | Agreement |
Two agreements out of ten. Four drives that one vendor bans outright sit on the other's Verified list, the strongest word that page uses. The Kingston row carries a caveat: Geekworm writes Kingston NV3 and SunFounder writes Kingston SNV3S. Kingston's listing for the NV2 gives its part number as SNV2S/1000G, so SNV3S is very likely the NV3 under its part number. That one is inferred from the numbering scheme, not from a datasheet.
One list contradicts itself on the same page
Before blaming either vendor, I checked each list against itself. SunFounder's WD Blue SN580 appears in the Verified table at 512GB and in the Compatible (May Vary) list as WD Blue SN580 series. The WD Blue SN550 sits in Verified at 256GB and in Generally Stable. A drive lands in the top tier and the hedged tier at once only if the tiers were assembled from different reports and never reconciled.
The second check was more telling. SunFounder publishes this page separately for the Pironman 5 and the Pironman 5 Pro MAX. I hashed all four sections on both pages: identical. Whatever these ratings are, they are not per-product test results.
Geekworm's list has its own version of this. Two entries, the WD Blue SN550 and the WD Green SN350, are annotated Solved! — the SN550 pointing at an rpi-eeprom-update from 2024-01-24. They are marked as fixed and still printed on the avoid list, on a page edited in June 2026. That single detail explains the SN550 contradiction: one vendor removed a stale entry and the other did not.
The stated cause does not survive a controller check
Geekworm's list opens by naming a culprit: We recommend avoiding the following NVMe SSDs equipped with a Phison controller, as they have been proven to have compatibility issues. Seven of the fourteen entries are WD SN-series drives. The WD Black SN770 uses SanDisk's in-house Polaris MP16+, a proprietary Western Digital design, not a Phison part. The list undercuts itself two lines later by annotating the fanxiang S500 Pro as carrying a Maxio MAP1202 controller, and further down it raises the Polaris controller as a separate suspect.
The heading hands a buyer one heuristic, avoid Phison, for a list that is mostly not Phison. The page even tells you to confirm it with lspci.
Three layers, one verdict
What the lists actually record is failure, and failure comes from at least three places. Only one of them is the drive.
Layer 2 has the clearest evidence. A Pimoroni staffer explaining why WD drives misbehave on their NVMe Base wrote: These drives need the extra SUSCLK clock signal to function. If it's not present, the drive sulks. The extra clock, they added, is not provided on the PCIe connector. That is a property of the adapter, and it explains why WD drives dominate incompatibility lists without any Phison part being involved.
Layer 1 is the one buyers create themselves. Raspberry Pi's own M.2 HAT+ documentation states plainly that The Raspberry Pi 5 is not certified for Gen 3.0 speeds. PCIe Gen 3.0 connections may be unstable. A Raspberry Pi forum user running a Netac NV2000 reported no errors at Gen 2, then BadTLP AER errors at Gen 3 climbing to 46,069 and ending in kernel panics even with ASPM disabled. Others in the same thread ran Kingston NV2 drives at Gen 3 for weeks with zero errors. Same setting, opposite outcome, and the lists record none of that context.
What that Gen 3 gamble actually buys
The Netac thread contains the number that ends the argument for me. That user's benchmark scored 44,516 at Gen 3 and 38,389 at Gen 2 — a 15.9% gain, paid for with 46,069 error events and kernel panics.
I cannot test that on a Pi 5, because I do not own one. What I can measure is the workload people build these machines for. My 24/7 agent server publishes this blog and runs scheduled jobs on ten slots a day, so I read its disk counters with iostat.
Since the last boot, 5.54 days earlier, disk0 had moved 4,022,909 MB across 192,533,827 transfers, averaging 21.40 KB per transfer. That is 8.40 MB/s sustained, or 1.68% of the 500 MB/s a PCIe Gen 2 x1 link already delivers. Averages hide bursts, so I also took 152 one-second samples: mean 7.43 MB/s, median 2.01, p90 19.50, peak 68.67. The single worst second used 13.73% of the link the Pi 5 is already certified for.
Transfer size matters as much as the total. At 21.40 KB per transfer this is a small-I/O workload, and small-I/O behaviour is not what the 3,500 MB/s number on the box measures. I ran the same check on the network side before buying a 2.5GbE USB adapter for a Mac mini, reached the same conclusion, and did not buy one.
How I would buy one
None of these drives has been in a Pi 5 of mine; what follows comes from the lists assembled above, not from my own bench.
Set the PCIe link to Gen 2 and leave it there. That one choice removes the failure mode behind most of the dramatic reports, and by my own numbers it costs a workload like mine nothing. Then pick a drive that appears positively across independent lists and on none of the ban lists.
- Samsung 980 — SunFounder lists it as Verified at 250GB, 512GB and 1TB and again under Generally Stable, and it appears on no incompatibility list I collected. It is a PCIe 3.0 drive, which on paper is the point: there is no Gen 4 headroom to be tempted by.
- Kingston NV2 (SNV2S) — Generally Stable on SunFounder, and the drive forum users reported running at Gen 3 for weeks without errors. Note that Geekworm bans the NV3, a different and newer model.
- Crucial P3 — a split verdict, reported as split: SunFounder has the 1TB in Verified and also lists the P3 under May Vary. The riskier of the three.
Skip the two drives both lists agree on: the WD SN740 and the Inland TN446. An owner also reports the WD Black SN850X 4TB being not seen on the bus no matter what I tried, and Geekworm lists the Micron 2450 and 2200 as detected but unable to boot. Whatever you pick has to be an M-key NVMe drive; M.2 SATA sticks fit the slot and never appear.
The drive is not the whole bill either. A Pi 5 driving an SSD wants the 5V/5A supply, and the economics of the whole machine are worth checking against the Raspberry Pi 5 versus Mac mini price math first. If the drive will hold a database or backups, portable SSD warranty and TBW numbers matter more than sequential speed, and heat is real enough that I wrote up whether an SSD can overheat after watching one of mine climb.
FAQ
Why do Raspberry Pi 5 NVMe compatibility lists contradict each other?
Because they publish a verdict against the drive while the documented causes sit elsewhere: the adapter board's missing SUSCLK signal, a user-forced PCIe Gen 3 link that Raspberry Pi does not certify, and EEPROM firmware age. Two vendors testing the same drive on different boards at different link speeds record opposite results, and neither records which.
Should I force PCIe Gen 3 on a Raspberry Pi 5?
Raspberry Pi's documentation states the Pi 5 is not certified for Gen 3.0 and that such connections may be unstable. One forum user measured a 15.9% benchmark gain at Gen 3 alongside 46,069 AER errors and kernel panics. On my own always-on server the sustained disk load is 8.40 MB/s, or 1.68% of what Gen 2 already provides, so the headroom would go unused.
Will an M.2 SATA SSD work on a Raspberry Pi 5?
No. The Pi 5's PCIe interface carries the NVMe protocol only, so an M.2 SATA or AHCI drive will not be detected even though it fits the slot physically. Use an M-key NVMe drive in a 2230 or 2242 form factor for the official M.2 HAT+.
Update, 2026-08-16: the same audit run against spinning disks produced a sharper version of this failure. Seagate's CMR/SMR list page shows no SMR anywhere in the SkyHawk family while Seagate's own SkyHawk datasheet marks ST4000VX013 as SMR — one vendor contradicting itself rather than two vendors contradicting each other. I wrote it up in CMR vs SMR: how to tell, and where vendor lists fail.
