CMR vs SMR: How to Tell, and Where Vendor Lists Fail
Seagate publishes a page called CMR and SMR Hard Drives, which exists to answer one question: is the drive I am about to buy shingled or not. For SkyHawk it answers cleanly — CMR at 1TB, 2TB, 4TB, 6TB and 8TB, and the SMR column reads N/A.
Seagate's own SkyHawk datasheet, document DS1902-17-2107US, has a row labelled Recording Technology. Under the 4TB model ST4000VX013, that row reads SMR.
Same company, same product family, two answers — and the one that is wrong is the page written specifically to stop you from buying the wrong drive.
What I actually collected
I have no hard drives. The machine this business runs on is a Mac mini with a single internal 500GB NVMe SSD and nothing attached — diskutil list shows zero external disks. Nothing below is a review. What I did instead was audit the paperwork, which is tedious rather than difficult, and so mostly goes undone.
The audit covers, as of 2026-08-16: Seagate's CMR/SMR list page (8 families in 3.5-inch, 3 in 2.5-inch); Seagate's SkyHawk datasheet DS1902-17-2107US, which carries a per-model Recording Technology row for 5 part numbers; the SkyHawk product manual 100870481a (Rev A, 2020-07-01); Western Digital's support answer 29458, last modified 2026-06-16; Toshiba's consumer HDD pages; and the TrueNAS community's SMR list, roughly 30 part numbers across four vendors. Every product claim below is a vendor spec sheet or a community report, and I say which.
Two 4TB SkyHawks, one differing row that matters
The datasheet lists three 4TB SkyHawk models side by side. ST4000VX016 and ST4000VX007 are marked CMR. ST4000VX013 is marked SMR. Reading down the full specification column for ST4000VX013 against ST4000VX016, exactly two rows differ: recording technology, and the maximum drive-reported operating temperature (70°C against 65°C).
Every other row matches: interface, 256MB cache, 180TB/year workload rate limit, 1,000,000-hour MTBF, 3-year warranty, 3.7W average operating power, 490g, 16 bays, 64 cameras. That includes the headline performance number, which defeats the usual advice to compare the specs. Both are rated at 180MB/s maximum sustained transfer at the outer diameter, because that figure describes a burst on fresh media rather than what happens when you write to the drive for six hours straight.
The list page contradicts itself too
The SkyHawk case is a disagreement between two documents. The Exos row is a disagreement inside one table. On that same CMR/SMR page, Exos appears as CMR at 4–24TB, as Mozaic HAMR CMR at 28–32TB, and as SMR at 32–44TB. A 32TB Exos therefore sits in a CMR column and an SMR column simultaneously.
That is structural rather than sloppy. The page is organised by family and capacity, while recording technology is a property of the part number, and no amount of care makes a family-and-capacity table answer a part-number question. The page carries no part numbers, no last-updated date, and no footnote on how to check an individual drive.
The other two vendors have the same gap elsewhere. Western Digital's support answer, last modified 2026-06-16, is clear that WD Red is SMR while Red Plus and Red Pro are CMR, but carries no model numbers. At retail, what separates the two is the word "Plus" and a part-number suffix: WD40EFAX is SMR, while WD40EFRX, WD40EFZX, WD40EFPX and WD40EFZZ are CMR. Four part numbers, one product name. Toshiba splits inside a family instead: P300 is CMR at 1–3TB and SMR at 4TB and 6TB. I found no current Toshiba page listing recording technology across its range.
Why this is worth caring about, including the part that cuts against me
Western Digital describes the intended SMR workload as "short periods of access to the drive" producing "extremely low average throughput and plenty of idle time". That is a fair description of most home storage, and an unusually fair description of ours.
Measured on this machine at 09:06 KST on 2026-08-16, 5.60 days after boot, iostat -Id disk0 reports 4,066,609.83 MB across 195,429,576 transfers, averaging 21.31 KB per transfer, or 8.40 MB/s sustained. Sampling one-second intervals 149 times gave a mean of 8.26 MB/s and a median of 2.29 MB/s, with a p90 of 22.48 and one spike to 277.17 MB/s. Two caveats: macOS iostat does not separate reads from writes, so that is combined traffic, and this is an NVMe SSD rather than a hard drive. It characterises the workload, not the medium.
By WD's own criterion our daily load belongs on the SMR side of the line — low average throughput, long idle stretches, small transfers. If day-to-day use were the deciding factor I would have no argument against a shingled drive. The deciding factor is the rebuild. When a drive in an array dies, the replacement gets written end to end at whatever speed it can manage, continuously, for as long as it takes. That workload has nothing in common with your daily average, and it arrives on the worst day.
What a rebuild costs, arithmetically
Taking 4TB as 4,000,000 MB the way drive vendors count it, and using sustained write rates from the sources above:
| Sustained write rate | Time to write 4TB | Where the rate comes from |
|---|---|---|
| 180 MB/s | 6.2 hours | SkyHawk datasheet, max sustained at outer diameter |
| 8.26 MB/s | 5.6 days | our measured average, shown as a reference line |
| under 6 MB/s | 7.7 days | rate reported during a stalled resilver |
The bottom row is not hypothetical. A user in the OpenZFS issue tracking WD EFAX resilver failures reported a resilver taking 8 days rather than the usual 24 hours, at write speeds below 6MB/s. Six MB/s across 4TB computes to 7.7 days, close to the 8 they observed. That is a consistency check rather than proof, since I do not know their array size or RAID level, but the ratio is the point: 180 over 6 is a factor of 30.
What owners actually report
The OpenZFS issue, opened 2020-04-16 and since closed, is titled "WD WDx0EFAX drive unable to resilver". Reporters describe the drive stalling outright: "this drive is unable to resilver. It has effectively hanged at 27%, IOPS fell to zero", followed by "write error count is going up" and "I will be returning this drive as not fit for purpose". Kernel logs show repeated DID_SOFT_ERROR on writes.
The TrueNAS community's list of known SMR drives states the mechanism plainly: SMR "has worse sustained write performance than CMR, which can cause severe issues during resilver or other write-intensive operations, up to and including failure of that resilver". The list exists at all because vendors were not identifying these drives.
The worst outcome is not a slow rebuild. The Rossmann Group, a data recovery shop, describes what reaches their bench: once the drive's CMR media cache fills, "typically within the first 20-50GB", the drive stalls doing read-modify-write on shingled zones. RAID controllers and ZFS enforce command timeouts of 8 to 20 seconds, so the controller "throws an IDNF error and drops the drive from the array". That abrupt disconnection can corrupt the drive's internal translator mid-update, turning a drive that was merely slow into one that is unreadable. Western Digital faced a 2021 class action over shipping these into the NAS channel, after the story broke through Hacker News and Blocks & Files in April 2020.
How to actually tell
Drive-managed SMR presents itself to the operating system as an ordinary disk. That is the design goal, and it is why the whole controversy was possible: you generally cannot interrogate a drive and have it confess. The part number is the handle you have.
- Get the full part number before buying, not the family name and capacity. "WD Red Plus 4TB" is four different part numbers; "SkyHawk 4TB" is three.
- Open the datasheet for the product line and find the
Recording Technologyrow. Where a vendor publishes it per model, as Seagate does for SkyHawk, it is authoritative in a way the summary page is not. Note that the product manual for the same drives, document 100870481a, never mentions SMR or CMR at all. - Cross-check against the community list, because it is indexed by part number and it caught models the vendors had not labelled.
- Treat matching performance specs as no evidence. The two 4TB SkyHawks advertise the same 180MB/s.
The cheap shortcut is to buy a drive whose retail title spells out CMR. Two that do, picked for that reason rather than from testing, are the WD Red Plus 4TB (WD40EFPX) and the Seagate IronWolf 4TB (ST4000VNZ06/006); I have run neither, so that is a listing-title claim and nothing more.
This is the same failure I hit yesterday auditing the Raspberry Pi 5 NVMe compatibility list, where two vendors contradicted each other on the same drives. Storage decisions keep coming down to whether a document is organised at the granularity of the thing being decided. If you are choosing between a Mac mini server and a NAS, or setting up Time Machine backups to a NAS, check this row before ordering — the same gap turns up in portable SSD warranty and TBW terms and in whether an SSD can overheat.
FAQ
How can I tell if a hard drive is CMR or SMR?
Find the exact part number, then look for a Recording Technology row in the manufacturer's datasheet for that product line. Family-and-capacity summary pages are not reliable, because recording technology varies between part numbers of the same family and capacity.
Is SMR always bad?
No. For sequential writes with idle time between them, which is how WD describes the intended use, SMR is fine and cheaper per terabyte. The problem is RAID rebuild and ZFS resilver, where the drive is written continuously and can stall past the controller's timeout.
Are vendors still shipping undisclosed SMR in 2026?
The disclosure exists now, but at the wrong granularity. As of 2026-08-16 Seagate's CMR/SMR page lists no SMR in the SkyHawk family while Seagate's own SkyHawk datasheet marks ST4000VX013 as SMR, and it shows Exos 32TB in both a CMR and an SMR column.
