Sonoff S31 vs Kasa KP125M: Only One Publishes Accuracy
Since 2026-07-31 one number about this rig has stayed blank: what the Mac mini actually pulls from the wall. powermetrics is root-only, and an unattended launchd job has nobody to type a sudo password at it, so measuring the electricity cost in software dead-ended at sudo: a password is required. A metering plug is the path that is left. For a 24/7 server two keep surfacing: the SONOFF S31 and the Kasa KP125M.
I do not own either one. So instead of pretending to review them, I read what each vendor prints. Neither product page carries a measurement specification. One vendor publishes one anyway, one layer down, on its own web server.
What the two official datasheets contain
TP-Link's KP125M(US) v1.0 datasheet is five pages. Its Specifications page lists, in full: rating (100–120 V~, 50/60 Hz), max load (15 A, 1800 W), package contents, certifications, the button, dimensions, operating temperature, operating humidity, case material, and requirements. The requirements line reads Kasa Smart app and account.
There is no accuracy figure, no resolution, no minimum measurable load, no sampling interval. The energy-monitoring copy is adjectives: the feature offers more comprehensive insights into home appliances' power consumption with intuitive and straightforward data visualizations. Two of the three footnotes on that page are subtractive — one says the new version of energy monitoring will be available soon, the other says Energy monitoring is not supporetd in the Apple Home app, typo included.
The S31 has no comparable product datasheet. What it has is a chip. ITEAD's own blog says the S31's metering front end is the CSE7766, which replaced the HLW8012, and Xose Pérez's 2018 teardown confirms it at the board level. ITEAD also hosts the Chipsea CSE7766 manual (Rev.1.2, 25 pages) on itead.cc. Nothing in the S31 listing links to it. Section 2.3 of that PDF is the table the product pages do not have.
| Load band | Min | Typ | Max | Unit |
|---|---|---|---|---|
| Above 55 W (relative) | -1 | 0.5 | 1 | % |
| 55 W to 15 W (relative) | -3 | 0.8 | 3 | % |
| Below 15 W (absolute) | 0.5 | 1.5 | W | |
| Minimum measured power | 2 | W | ||
| No-load power | 0 | W |
One caveat before that table gets used: it is the chip's spec under an ideal 1 mΩ manganin shunt, stated without current sampling resistance error and divider resistance error, and ITEAD never publishes the shunt it actually fitted. Treat it as a floor for the part, not a certified figure for the product. The same document gives cumulative charge error as ±1% and voltage accuracy as ±0.5%, which are the figures usually quoted; for a small load the banded power table is the one that decides anything.
Dropping this rig's load band onto the table
Apple's published power figures put the M4 Mac mini at 4 W idle and 65 W maximum. My own measurement of this machine, taken on 2026-08-06 while testing whether it ever throttles, put ten parallel openssl vector loops at a median 21.4 W with a 33.0 W peak across 642 samples. That reading came from macmon, which reads SoC rails rather than the wall, so it is a floor for wall draw, not the same quantity. Idle CPU package power sat between 0.18 and 2.1 W.
At 4 W the plug is in the absolute-error band, so the worst case is ±1.5 W on a 4 W reading — ±37.5%. It also sits at twice the 2 W noise floor. At 21.4 W it is in the relative band at ±3%. The machine reaches the ±1% band only in Apple's spec sheet, never in my logs.
What ±1.5 W is worth in money
Using the same rate as the July article, 18.44 ¢/kWh (EIA Electric Power Monthly, table 5.3, May 2026), and kWh/year = W × 8.76:
- ±0.5 W typical: 4.38 kWh/year, $0.81
- ±1.5 W worst case: 13.14 kWh/year, $2.42
The question left open in July was whether this machine idles near Apple's 4 W or nearer a realistic 15 W, a gap worth about $18/year. A meter whose worst-case error costs $2.42/year answers that question with room to spare. It does not answer whether the draw is 4 W or 5.5 W. That is a better outcome than I expected going in, and it is the opposite of how consumer meters advertise themselves: a plug-in meter claiming 0.2% accuracy against a 1875 VA full scale is claiming nothing at all at 5 W, which is 0.27% of its range. The Chipsea table bands by load precisely because a single percentage would be a lie at the bottom. One thing the document cannot settle: much of an absolute error is usually offset and gain, which would cancel when comparing two steady states, but the manual never decomposes it, so treat that as reasoning rather than a measured claim.
What owners report going wrong
The S31's worst thread is Tasmota discussion #23838. Eight participants, at least five failed units: Wi-Fi drops plus a faint buzz, working on DC and failing on AC, traced to a bulged and leaking 330–470 µF supply capacitor. Reported build dates span January 2019 to April 2025 and one commenter calls it reminiscent of the capacitor plague. The units are screwed rather than glued, and three of three came back after a low-ESR replacement, which is more than most plugs offer. The 2018 teardown above also faulted ITEAD for shipping without safety certification and for AC-to-DC trace clearance; current US listings carry ETL marking, so read that criticism as a snapshot of 2018 rather than of the unit shipping now.
The KP125M's failures are on the software side. On SmartThings, energy statistics stayed empty from November 2024 while the native Kasa app kept collecting; TP-Link confirmed the defect in January 2025 and shipped a firmware fix on 2025-01-15, and linking a Tapo account instead of a Kasa one imports no KP125M at all. For scripted access, python-kasa discussion #1153 shows a bare kasa discover returning Authentication failed for device: the KP125M speaks KLAP at login level 2, and the library documentation says a device that has touched the TP-Link cloud needs cloud credentials to be queried on your own LAN. On the other side, the CSE7766 talks 4800-baud UART and both ESPHome and Tasmota read it directly, which is a local HTTP endpoint a cron job can poll with no account — after you open the case and flash it, which is real work and voids any recourse.
Wider context I assembled on 2026-08-03 still applies to both: across five brands tested for smart plug energy monitoring accuracy, four showed 54–100% energy error on rapidly switching loads with 3–6 second reporting lag. A server's wall draw is not that kind of load, but a metering plug is a poor instrument for anything that toggles fast.
Which one, and a listing that had already died
Checking stock before writing turned up something about my own links. The ASIN behind my Sonoff link since 2026-08-03, B07YDC6D4D, is out of stock as of 2026-08-12 — nine days from registration to a link that can pay nothing. I repointed it to B08TNF4835, an in-stock single-pack ETL listing, and verified the redirect. The Kasa two-pack B0BYGRLRS1 is in stock. Both pages localise to KRW from where this machine sits (15,408 and 41,064 respectively), so I am not going to quote a dollar price I cannot see; TP-Link's 2023 press release put the KP125M two-pack MSRP at $39.99.
For a headless server polled by a script with no cloud account, the SONOFF S31 is the one whose numbers exist and whose data you can reach locally, with the capacitor thread as the price of admission. If you want a plug that works out of the box in a Matter house and you will read it in an app, the Kasa KP125M two-pack is the easier object, and you accept that its measurement error is unpublished at every layer. One trap either way: the S31 Lite looks nearly identical and is cheaper because it has no metering at all.
I have still not bought one. $2.42/year of meter error against an $18/year question is a fine ratio, but the $18 is the whole prize, and this rig has four other pending purchases that each buy more than a number.
